KR-F Panel

KR-F Panel

RFID Cabinet Lock

Download pdf
  • Model
    KR-F Panel
    Size of lock body
    ABS+Zinc Alloy
    CE;FCC; RoHS
    6V(4*1.5V AAA batteries)
    Unlock way
    RFID Card/Bluetooth(available customized)
    Working temperature
    Working humidity
    5% ~ 85%RH
    Working life
    500000 times

    • Low voltage alarm: When the voltage is lower than 4.5V, there will be a sound and light prompt every time the lock is unlocked. And when the voltage is lower than 4V, it can be automatically unlocked and cannot be locked.
    • Emergency unlocking: When the battery is dead, the Micro USB connector/3.5mm socket is used to connect an external battery box or power adapter.
    • Color: a variety of colors to choose from.
    • High frequency card: MF1, 13.56MHz, also supports other types of mifare cards
    • Cards of different shapes can be provided: wristbands, tags, cards, etc.
    • Support custom functions: automatic unlocking at regular intervals, the mobile phone displays the locker number, one card can only work on one lock at the same time, etc.
    • Two power supply methods: 4*1.5VAAA battery and 6V DC. If necessary, 12V DC can also be used.
    • A variety of working modes are available: suitable for applications in different places. The user can use the mobile APP to control the lock.
    • Installation method: vertical installation and horizontal installation, suitable for various occasions.
